Factor 55 FlatLink XTV Winch Shackle Mount (Gray) Upgrade your UTV/ATV winching setup with the FACTOR 55 FlatLink XTV Winch Shackle Mount. This gray, closed-system mount replaces the conventional winch hook with a safer, stronger shackle and D-ring style connection—built for secure recoveries and reduced risk. Key Features Closed system winching with a folding, low-profile design for improved approach angles Easy installation with simple snap ring removal for shear pin service No splicing required; compatible with steel cable or synthetic rope up to 5/16 in Ultra-secure rope eye retention using a 7/16" diameter 6Al-4V titanium double-shear pin with internal snap ring EPDM rubber guards with barbed tips protect fairleads and help prevent rattling Works with common 1/2" and 5/8" shackles (pin and bow end), soft shackles up to 7/16" , and pin-end of 3/4" shackles Intended for winches rated 6,000 lb capacity or less Specifications Load Capacity: 6000 lb Rope Diameter: 5/16" Material: Aluminum (precision machined) with titanium pin (6Al-4V) Type: Winch shackle mount Finish/Color: Anodized Gray Weight: 12.7 oz (0.95 lb)
The FlatLink XTV allows UTV and ATV winch owners to replace the conventional winch hook with a safer and stronger shackle and D-Ring
Closed system winching with a folding, low-profile design for better approach angles
Easy to install - simple snap ring removal for shear pin
Does not require splicing and is compatible with steel cables or synthetic ropes up to 5/16 inches
The rope eye is retained in the FlatLink XTV with a 7/16” diameter 6AI-4V grade V titanium double-shear pin and internal snap ring for an ultra-secure connection
EPDM rubber guards are attached with four barbed tips and protects fairleads and prevents rattling
Works with common 1/2” and 5/8” shackles (pin and bow end), soft shackles up to 7/16”, and the pin-end of 3/4” shackles
Intended for use with winches 6,000 lbs. in capacity or less
Precision machined from 6000 series Aaluminum Aand 6Al-4V titanium
